7.4.2 Transmission Oil
Inspection
1. Park machine on a horizontal surface.
2. Check the transmission oil level in the oil level gauge.
Transmission oil amount: See page 28
Adding
1. Remove the oil filler plug.
2. Pour the specied oil into the oil port.
Oil to use: See page 28
Replacement
1. Prepare a suitable container to collect drained oil.
2. Remove oil drain plug and drain oil from crankcase.
Maintenance
5313M-0704-010
5313M-0704-020
5313M-0704-030
Avoid contact with high temperature oil to avoid burns.
3. Replace the drain plug firmly.
4. Open the oil cap and add proper amount of designated
oil.
5. Replace the oil cap firmly.
Dispose of the drained oil properly.
To Next Page
