Chikusui Canycom CM 221 - HST Oil

- 32 -
7.4.3 HST Oil
Replacement
1. Prepare a suitable container to collect drained oil.
Avoid contact with high temperature oil to avoid burns.
Inspection / Adding
1. Park the machine on a horizontal surface.
2. Remove the right side cover.
3. Check the cutter blade case oil level gauge. If the oil
level is low, add oil.
Oil to use : See page 28
Maintenance
�
Cap
HST oil tank
5316M-0601-010
Oil level gauge
Drain plug
5316M-0601-020
2. Remove the drain plug and drain oil.
3. Replace the drain plug.
4. Open the oil cap and add proper amount of designated
oil.
5. Replace the oil cap.
Dispose of the drained oil properly.
Control oil flow to avoid overflows
