02
Installation
3
1) Outline and installation dimensions
2) On-off indication
Red
Green
I•ON
O•OF F
78
-1 .20
0
86
-1.40
0
49.5±0.31
45±0.31
1P
2P
3P
4P
18
-0.43
0
36
-0.62
0
54
-1.20
0
72
-1.20
0
Unit:mm
