NVF5 Series User Manual Chapter 3 Installation and Wiring
3.2.1 Input AC Reactor Descriptions
The AC input reactor are used to reduce harmonics and improve impedance.When
the enviroment need higher harmonic requirements,an optional AC input reactor should be
selected.Please refer to the reactor specifications of reactor provider below.
Power
Supply
Catalog No.
Input Current
A
AC input reactor
Three-Phas
e
AC380V~440
V
NVF5-0.4/TS4-B 2.3 ACL-00037-AL8M40-2L
NVF5-0.75/TS4-B 3.3 ACL-00037-AL8M40-2L
NVF5-1.5/TS4-B 5.1 ACL-00050-AL4M20-2L
NVF5-2.2/TS4-B 6.6 ACL-00075-AL3M00-2L
NVF5-3.7/TS4-B 12.1 ACL-0010-AL2M20-2L
NVF5-5.5/TS4-B 13.1 ACL-0015-AL1M42-2L
NVF5-7.5/TS4-B 22.2 ACL-0020-AL1M08-2L
3.2.2 Brake Resistor Description
Table 3.1 Brake Resistor Specifications
Catalog No.
Input Current
A
Recommend
ed Circuit
Breaker
A
Recommend
ed
Contactor
A
Cable
Specificatio
n
mm²
NVF5-0.4/TD2
5.4 16 10 2.5
NVF5-0.4/TD2-B
NVF5-0.75/TD2
10.3 25 16 2.5
NVF5-0.75/TD2-B
NVF5-1.5/TD2
15.5 32 25 4
NVF5-1.5/TD2-B
NVF5-2.2/TD2
20 40 32 6
NVF5-2.2/TD2-B
NVF5-0.4/TS4-B 2.3 10 10 2.5
NVF5-0.75/TS4-B 3.3 10 10 2.5
NVF5-1.5/TS4-B 5.1 16 10 2.5
NVF5-2.2/TS4-B 6.6 16 10 4
NVF5-3.7/TS4-B 12.1 25 16 4
NVF5-5.5/TS4-B 13.1 32 25 6
NVF5-7.5/TS4-B 22.2 40 32 6
