CHINT NVF5-2.2/TS4-B User Manual

NVF5 Series User Manual Chapter 4 Integral Keypad
Table 4.3 Correspondence between display symbols and characters / numbers
The 3 unit indicators correspond to units such as Hz, A, V and so on，Shown as figure
Figure 4-2-1 Unit Indicator Description
The 3 unit indicators 3：meaning shown as table 4.4
Table 4.4 Status Indicator Description
Indicator
Display
Current Status
Running Status
（
RUN
）
Light
Running Status
Light Off
Stop Status
Running Direction
（
F/R
）
Light
Running in default direction
Light Off
Running reverse
Fault
（
FAULT
）
Light
Fault Status
Light Off
Normal Status
LED
Display
Meaning
LED
Display
Meaning
LED
Display
Meaning
LED
Display
Meaning
0 A I S
1 b J T
2 C L t
3 c N U
4 d n v
5 E O y
6 F o -
7 G P 8.
8 H q .
9 h r k
Frequency Unit
Hz
○ Hz
Hz+A
A+V
Speed Unit
rpm
Percentage Unit
%
Current Unit
A
Voltage Unit
V
Unit Indicator
Description
○ A
○ V
- 28 -
