Notice to Electrician Chore-Tronics Model 16 & 8 Control
8
MT1554A 1/6/99
Each relay output in this Chore-Tronics
TM
control is designed to control 1 H.P. for
many years of service. The relays are single pole, normally open contacts and break
only one line of the power to the various loads. (The control is not to be considered
the disconnect device for motor loads.) If a load of more than 1 H.P. is controlled by
a relay in the control, additional contactors are required and some of the basic
flexibility of the control is compromised. It is very important that the owner/
integrator understands that the grouping of loads compromises flexibility.
It is recommended that the installation diagram on page 32 be used to configure the
house, and the relay decal inside the box is filled out completely. If this step is
completed prior to wiring, it will eliminate any unnecessary confusion. Filling out the
relay position decal will help to properly group the loads.
Notice to Electrician
9/9/98
