Chore-Tronics® Mobile Server Wiring
MT2471A
12
Ethernet Cat 5e-6 (CT3 and other Chore-Tronics Controls) Wiring
Ethernet Cable
Ethernet Cable
Ethernet Cable
Alarm Inputs to Broadcaster (Twisted Pair)
Fnet
Fnet
Fnet
CT3 Controls send specific Alarms directly
to the Broadcaster Main Box
ELT
Ethernet Cable
Broadcaster
Aux Box
Broadcaster
Main Box
8 dry Contact Inputs
CT3 Main Box
CT3 Main Box
Internet Router
Ethernet Switch
Ethernet Cable
CT3 Main Box
Ethernet Switch
(8 dry contact inputs)
Ethernet Switch
