Christ ALPHA 1-2 LDplus - 2.2. Preparation; 2.3. Freezing

4 • General Information Operating Manual Freeze Dryer ALPHA 1-2 LDplus
Physical data (without
vacuum pump):
Dimensions of the unit:
width: 315mm
height: 345mm
depth: 460mm
(incl. vacuum flange
connection)
Weight: approx. 28kg
Noise emissions according
to DIN 45635:
49 dB(A)
Electromagnetic
compatibility according to
EN 55011:
class B
Filling quantities:
Refrigerant:
see label on the back
of the unit
Connection requirements
with vacuum pump
0.4KVA:
Electrical connection:
230V / 50Hz (others
upon request)
Power consumption: 1,2kVA
Max. current: 5A
Fuse protection: 6,3A
Ambient temperature:
+10°C to +25°C
(higher temperatures
upon request)
