Programmable AC Source 61601/61602/61603/61604 Quick Start Guide
2. Installation
2.1 Inspection
After unpacking the instrument, please inspect any damage that may have
occurred during the shipment. Save all packing materials in case the
instrument has to be returned one day. If any damage is found, please file
a claim with the carrier immediately. Do not return the instrument to the
factory without obtaining the prior RMA acceptance from Chroma.
2.2 Preparation for Use
In the beginning, the instrument must be connected with an appropriate AC
line input. Then, since it is intelligently cooled by fans, it must be installed
in sufficient space for circulation of air. It should be used in an area where
the ambient temperature does not exceed 40°C.
2.3 Requirements of Input Power
2.3.1 Ratings
Input Voltage Range : 90 ~ 250 Vac, single phase
Input Frequency : 47-63 Hz
Max. Current : 61601: 8 A
61602: 16 A
61603: 21 A
61604: 28 A
CAUTION
The AC source will be damaged if it is operated at an
input voltage that is outside its configured input range.
2.3.2 Input Connection
The input terminal block is located on the rear panel of the instrument.
The power cord must be a three-conductor cord rated at least for 85°C.
The power line input must have a current rating which is greater than or
2-1
