5-2
Table 5-1
Pin No.
INPUT/OUTPUT
Description
1
---
“N.C.”
2
INPUT
RxD
3
OUTPUT
TxD
4
---
DSR
5
---
GND
6
---
DTR
7
---
CTS
8
---
RTS
9
---
“N.C.”
Table 5-2 lists the connection between PC (IBM compatible) and 62000H Series DC Power
Supply.
Table 5-2
Pin No.
IBM PC
62000H
1
DCD
“N.C.”
2
RX
RX
3
TX
TX
4
DTR
“N.C.”
5
GND
DGND
6
DSR
“N.C.”
7
RTS
“N.C.”
8
CTS
“N.C.”
9
“N.C.”
“N.C.”
“N.C.” stands for “Not Connected”.
5.1.4 Connecting RS-485
The default transmission baudrate of 62000H Series is set to 115200 and the parity check is
set to None. The RS-485 interface is a half-duplex two-wire differential signaling transmission
and only RS485_P and RS485_N signals are required for data transmission. The connection
is the same as RS-232C that is a 9-pin D type male connector. Table 5-3 lists the pin number
and assigned signal of RS-485 connector.
Table 5-3
Pin No.
Description
1
---
2
---
3
---
4
RS485_P
5
---
6
---
