General Information
1-7
MODEL 63308 63312
POWER
60W 600W 120W 1200W
CURRENT
0∼2A 0∼20A 0∼24A 0∼240A
VOLTAGE
2.5∼500V 1∼80V
MIN. OPERATING VOLTAGE (DC)
2.5V at 2A 2.5V at 20A 1.0V at 24A 1.0V at 240A
CONSTANT CURRENT MODE
Range
0∼2A 0∼20A 0∼24A 0∼240A
Resolution 0.5mA 5mA 6mA 60mA
Accuracy 0.1%+0.1%F.S. 0.1%+0.2%F.S. 0.1%+0.1%F.S. 0.1%+0.2%F.S.
CONSTANT RESISTANCE MODE
Range
0.625Ω∼2.5KΩ (600W/125V)
25Ω∼100KΩ (600W/125~500V)
6.25mΩ∼25Ω (1200W/16V)
0.3125Ω∼1.25KΩ (1200W/16~80V)
Resolution 12 bits 12 bits
Accuracy
2.5KΩ : 50m
mho +0.2%
100KΩ : 5m mho +0.1%
25Ω : 0.8 mho +0.8%
1.25KΩ : 0.08 mho +0.2%
CONSTANT VOLTAGE MODE
Range
2.5∼500V 1∼80V
Resolution 125mV 20mV
Accuracy
0.05%±0.1%F.S. 0.05%±0.1%F.S.
DYNAMIC MODE
DYNAMIC MODE
C.C. MODE C.C. MODE
T1 & T2 0.025mS - 50mS/Res: 5uS
0.1mS - 500mS/Res: 25uS
10mS – 50S/Res: 2.5mS
0.025mS - 50mS/Res: 5uS
0.1mS - 500mS/Res: 25uS
10mS – 50S/Res: 2.5mS
Accuracy
1μS /1mS+100ppm 1μS /1mS+100ppm
Slew Rate
0.32∼80mA/μS3.2∼800mA/μS 0.004∼1A/μS 0.04∼10A/μS
Resolution
0.32mA/μS3.2mA/μS 0.004A/μS 0.04A/μS
Current
0∼2A 0∼20A 0∼24A 0∼240A
Resolution 0.5mA 5mA 6mA 60mA
Current Accuracy 0.4% F.S. 0.4% F.S.
MEASUREMENT SECTION
VOLTAGE READ BACK
Range
0∼125V 0∼500V 0∼16V 0∼80V
Resolution 4mV 16mV 0.5mV 2.5mV
Accuracy 0.05%+0.05% F.S. 0.05%+0.05% F.S.
CURRENT READ BACK
Range
0∼2A 0∼20A 0∼24A 0∼240A
Resolution 0.0625mA 0.625mA 0.75mA 7.5mA
Accuracy 0.1%+0.1% F.S. 0.15%+0.15% F.S.
PROTECTIVE SECTION
Over Power Protection
≒62.4W ≒624W ≒124.8W ≒1248W
Over Current Protection
≒2.04A ≒20.4A ≒24.48A ≒244.8A
Over Temperature Protection
≒85°C ≒85°C
Over Voltage Protection
≒510V ≒81.6V
GENERAL
SHORT CIRCUIT
Current (CC) -
≒20A
-
≒240A
Voltage (CV) - 0V - 0V
Resistance (CR) -
≒0.625Ω
-
≒0.00625Ω
INPUT RESISTANCE (LOAD OFF)
100KΩ (Typical) 100KΩ (Typical)
SIZE
162(W)× 172(H)×495(D) 324(W)× 172(H)×495(D)
WEIGHT (Approx.)
8.4Kg 16.8Kg
EMC & SAFETY
CE CE
∗ Before using CCL mode on model 63105 & 63108, it needs to set CC Vrange Select in Configuration to
2.LOW for access permission.
