Chroma 63802 - 3.9 AC Load Simulation - Rectified Load Mode

Local Operation
3-29
3.9 AC Load Simulation -- Rectified Load Mode
The general AC products like UPS and AC SOURCE often use rectified load to test their
features as Figure 3-8 shows. Based on the load network, rectified load mode is designed into
three sub modes – RLC mode, CP mode and Inrush Current mode.
The operating frequency should be lower than 70Hz under Rectified Load
Mode.
Zo
Vo
Io
Rs Ls
C
R
L
Vs
Source
Figure 3-10 Schema of rectified load
3.9.1 RLC Mode
For switching RLC mode, the procedures are as below:
1. Press RLC/DC RECT key to go into the Rectified Load Mode.
2. Press 1 , then press ENTER to enter RLC mode.
[
R
E
C
T
I
F
I
E
D
L
O
A
D
]
Rs Ls
R
L
C
C
H
O
O
S
E
=
1
1
.
R
L
C
M
O
D
E
2
.
C
P
M
O
D
E
3
.
I
N
R
U
S
H
C
U
R
R
E
N
T
Users are able to set the equivalent series resistance R
s
, equivalent series inductance L
s
,
equivalent parallel load capacitance C, equivalent parallel load resistance R
L
and I
rms
(max)
parameters for loading when operating in this mode. The UUT I
p
(max) value needs to be set
before loading and the parameter range for setting is listed in the specifications.
