Locating Tether Anchorages
There are tether strap anchorages located be-
hind all second row seating positions. The third
row has a tether anchor on the 40% seat for the
right outboard position and in the center of the 60% seat
for either the center or left outboard seating position. All
tether anchorages are located on the back of the seat, near
the floor.
LATCH Anchorages (Third Row 60/40 Anchorages
Shown)
Tether Strap Anchorages (Third Row 60/40 Anchorage
Shown)
