Vehicle Loading Chart
Follow these steps to determine the total weight the
vehicle can carry.
1. Determine the cargo capacity of your vehicle.
• Load Capacity = GVWR – Curb (weight of vehicle
full fluids NO Occupants).
2. Determine occupant count.
• For calculation purposes, average weight of an occu-
pant is 150 lb (68 kg).
EXAMPLE:
• GVWR = 6005 lbs (2723 kg)
• CURB = 4500 lbs (2041 kg)
• Load Capacity = GVWR – CURB = 6005 lbs (2723 kg)
- 4500 lbs (2041 kg) = 1505 lbs (682 kg)
4 Occupants (at 150 lbs [68 kg]) + Max Trailer =
• 1505 lbs (682 kg) – 600 lbs (272 kg) (4 x 150 lbs [68 kg])
– 360 lbs (163 kg) (10% of 3600 lbs [1632 kg]) = 545 lbs
(247 kg) of cargo in vehicle
512 STARTING AND OPERATING
