Cavity Cartridge Fuse Blade Fuse Description
F10 – – Not Used
F11 – – Not Used
F12 – 5 Amp Tan Battery Sensor (IBS)
F13 – – Not Used
F14 – 10 Amp Red ECM
F15 40 Amp Green – Power Locks
F16 – 20 Amp Yellow ECM
F17 30 Amp Pink – Starter
F18 40 Amp Green – CBC Feed #4 (Exterior
Lights #1)
F19 25 Amp Clear – 2nd Row Folding Seats
Solenoid LT
F20 – 10 Amp Red A/C Compressor Clutch
F21 25 Amp Clear – 2nd Row Folding Seat
Solenoid RT
7
IN CASE OF EMERGENCY 549
