Cavity Cartridge Fuse Blade Fuse Description
F56 – 10 Amp Red Front and Rear HVAC
Control Module/ESP/
ESC
F57 – – Not Used
F58 – – Not Used
F59 30 Amp Pink – 7 Way Connector Recep-
tacle — If Equipped
F60 – 20 Amp Yellow Rear Cargo APO
F61 – 20 Amp Yellow Trailer Tow Right Stop/
Turn — If Equipped
F62 – – Not Used
F63 – 20 Amp Yellow Trailer Tow Left Stop/
Turn — If Equipped
F64 – 15 Amp Blue RT HID Headlamp
F65 – – Not Used
7
IN CASE OF EMERGENCY 553
