4. Uncoil the power plug and insert
the plug into the vehicle’s 12 Volt
power outlet.
5. Uncoil the Hose and screw the fit-
ting at the end of hose onto the
valve stem.
6. Turn the Mode Select Knob and
turn to the Air Mode position.
7. Check the pressure in the tire by reading the Pressure
Gauge.
If tire pressure is less than 19 psi (1.3 Bar):
The tire is too badly damaged. Do not attempt to drive
the vehicle further. Call for assistance.
7
IN CASE OF EMERGENCY 593
