Fig. 177 Remove No. 1 Caged Needle Bearing
1 – #1 CAGED NEEDLE BEARING
2 – NOTE: TANGED SIDE OUT
Fig. 178 Remove Input Clutch Assembly
1 – INPUT CLUTCH ASSEMBLY
Fig. 179 Remove No. 4 Thrust Plate
1 – OVERDRIVE SHAFT ASSEMBLY
2 – #4 THRUST PLATE (SELECT)
3 – 3 DABS OF PETROLATUM FOR RETENTION
Fig. 180 Remove Front Sun Gear Assembly
1 – FRONT SUN GEAR ASSEMBLY
2 – #4 THRUST WASHER (FOUR TABS)
21 - 72 42LE TRANSAXLE LH
DISASSEMBLY AND ASSEMBLY (Continued)
