NOTE: The OD/UD Reaction Plate, Snap Rings, and
Input Clutches Retainer is not interchangeable with
previous year 41TE components. The snap rings
are thicker and the position of the ring lands have
changed.
(13) Remove the OD/UD reaction plate tapered
snap ring (Fig. 238).
NOTE: The OD/UD clutch reaction plate has a step
on both sides. Install the OD/UD clutches reaction
plate tapered step side up.
(14) Remove the OD/UD reaction plate (Fig. 239).
(15) Remove the first UD clutch disc (Fig. 240).
(16) Remove the UD clutch flat snap ring (Fig.
241).
Fig. 236 Underdrive Shaft Assembly
1 – #3 THRUST WASHER (5 TABS)
2 – UNDERDRIVE SHAFT ASSEMBLY
Fig. 237 No. 2 Needle Bearing
1 – #2 NEEDLE BEARING (NOTE 3 TABS)
Fig. 238 OD/UD Reaction Plate Tapered Snap Ring
1 – OVERDRIVE/UNDERDRIVE CLUTCHES REACTION PLATE
TAPERED SNAP RING
2 – SCREWDRIVER (DO NOT SCRATCH REACTION PLATE)
Fig. 239 OD/UD Reaction Plate
1 – OD/UD CLUTCH REACTION PLATE (STEP SIDE DOWN)
LH 42LE TRANSAXLE 21 - 87
DISASSEMBLY AND ASSEMBLY (Continued)
