Chrysler Concorde - Page 1272

Fig. 300 Install Low/Reverse Piston Return Spring
1 – LOW/REVERSE PISTON RETURN SPRING
2 – PISTON
Fig. 301 Low/Reverse Spring Compressor Tool
1 – TOOL 6057
2 – TOOL 5059
3 – TOOL 5058–3
Fig. 302 Compressor Tool in Use
1 – LOW/REVERSE CLUTCH RETURN SPRING
2 – SNAP RING (INSTALL AS SHOWN)
3 – TOOL 5058A-3
4 – TOOL 5059A
5 – SPECIAL TOOL 6057
Fig. 303 Install Snap Ring
1 – SNAP RING OPENING MUST BE BETWEEN SPRING
LEVERS (AS SHOWN)
2 – SNAP RING PLIERS
3 – TOOL 6057
LH 42LE TRANSAXLE 21 - 103
DISASSEMBLY AND ASSEMBLY (Continued)
