Chrysler Concorde - Page 850

Connector
Name/Number
Color Location Fig.
Data Link
Connector
BK LT Side of
Steering
Column
8
Decklid Release
Switch
BK Left Side of I/P 8
Driver Door
Courtesy Lamp
Left Front Door N/S
Driver Door
Cylinder Lock
Switch
Left Front Door N/S
Driver Door Lock
Motor/Ajar Switch
Left Front Door N/S
Driver Door
Speaker
Left Front Door N/S
Driver Heated
Seat Switch
YL At Driver Seat N/S
Driver Heated
Seat Cushion
BK At Driver Seat N/S
Driver Heated
Seat Back
GN At Driver Seat N/S
Driver Power
Door Lock Switch
Left Front Door N/S
Driver Power
Mirror
Driver Door N/S
Driver Power
Mirror (Memory)
NAT Driver Door N/S
Driver Power
Seat Front Riser
Motor
At Driver Seat N/S
Driver Power
Seat Front Riser
Sensor
BK At Driver Seat N/S
Driver Power
Seat Horizontal
Motor
At Driver Seat N/S
Driver Power
Seat Horizontal
Motor Sensor
BK At Driver Seat N/S
Driver Power
Seat Rear Riser
Motor
At Driver Seat N/S
Driver Power
Seat Rear Riser
Motor Sensor
At Driver Seat N/S
Driver Power
Seat Recliner
Motor
At Driver Seat N/S
Connector
Name/Number
Color Location Fig.
Driver Power
Seat Recliner
Motor Sensor
BK At Driver Seat N/S
Driver Power
Seat Switch
BL At Driver Seat N/S
Driver Power
Window Motor
BK Left Front Door N/S
Driver Power
Window Switch
BL Driver Door N/S
Driver Sail
Speaker
Driver Door N/S
Driver Side
Airbag
Left B Pillar N/S
EGR Solenoid BK Rear of Engine 5, 6
Engine Coolant
Temp Sensor
BK Front of Engine 5, 6
Engine Oil
Pressure Switch
(2.7L)
GY Right Side of
Engine
5
Engine Oil
Pressure Switch
(3.5L)
GY Left Side of
Engine
6
Engine Starter
Motor
NAT Left Side of
Engine
5, 6
EVAP/Purge
Solenoid
BK Right Front of
Engine
Compartment
1
Evaporator
Temperature
Sensor
On HVAC Unit N/S
Fuel Injector # 1 BK At Injector 5, 6
Fuel Injector # 2 BK At Injector 5, 6
Fuel Injector # 3 BK At Injector 5, 6
Fuel Injector # 4 BK At injector 5, 6
Fuel Injecotr # 5 BK At Injector 5, 6
Fuel Injector # 6 BK At Injector 5, 6
Fuel Pump
Module
GY Center Rear of
Trunk Area
N/S
G100 Rear of Block
Right Side
5, 6
G101 Rear of Block
Left Side
5, 6
G102 Left Headlamp N/S
G103 Left Headlamp N/S
G104 Left Headlamp N/S
LH 8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 3
DESCRIPTION AND OPERATION (Continued)
