Connector
Name/Number
Color Location Fig.
G105 Near Right
Horn
2
G106 Near Right
Horn
2
G107 Left Side of
Transmission
7
G108 Near Power
Distribution
Center
N/S
G200 Lower Center
of Instrument
Panel
9
G201 Lower Center
of Instrument
Panel
9
G300 Under Driver
Seat
11
G301 Under
Passenger
Seat
10
G303 Fuel Pump
Ground
N/S
G400 Deck Lid
Ground
14
Generator BK Rear of
Generator
5, 6
Generator Output Rear of
Generator
7
Glove Box Lamp BK At Lamp 9
Headlamp Switch BL At Switch 8
Headlamp
Washer Pump
Motor
Near Left
Headlamp
N/S
Idle Air Control
Motor
BK On Throttle
Body
5, 6
Ignition Switch BK At Switch 8
Instrument
Cluster C1
GN Rear of Cluster 8
Instrument
Cluster C2
BL Rear of Cluster 8
Intake Air Temp
Sensor (2.7L)
GY Rear of Intake N/S
Intake Air Temp
Sensor (3.5L)
GY Left Side of
Engine
6
Joint Connector In Power
Distribution
Center
N/S
Connector
Name/Number
Color Location Fig.
Junction Block
C1
BK Left Side of I/P 8
Junction Block
C2
GY Left Side of I/P 8
Junction Block
C3
BL Left Side of I/P 8
Junction BLock
C4
GN Left Side of I/P 8
Junction Block
C5
WT Left Side of I/P 8
Junction Block
C6
Left Side of I/P 11
Junction Block
C7
Left Side of I/P 11
Junction Block
C8
GN Left Side of I/P 11
Junction Block
C9
OR Left Side of I/P 11
Junction Block
C10
GY Left Side of I/P 11
Junction Block
C11
NAT Left Side of I/P N/S
Knock Sensor
(2.7L)
GY Under Intake
Manifold
N/S
Knock Sensor
(3.5L)
BK Under Intake
Manifold
N/S
Leak Detection
Pump
BK Center of
Trunk Area
N/S
Left Side Impact
Airbag Control
Module
YL Left B Pillar 11
Left Back-Up
Lamp
At Lamp N/S
Left Fog Lamp GY At Lamp 3
Left Rear Fog
Lamp
At Lamp N/S
Left Front
Park/Turn Signal
Lamp
BK At Lamp N/S
Left Front
Position Lamp
GY At Left
Headlamp
3
Left Front Side
Marker Lamp
NAT At Lamp N/S
Left Front Wheel
Speed Sensor
BK At Sensor 4
Left Headlamp
Leveling Motor
BK At Left
Headlamp
3
8W - 90 - 4 8W - 90 CONNECTOR/GROUND LOCATIONS LH
