SERVICING AND MAINTENANCE 377
F76 – 20 Amp Yellow Uconnect/DCSD/Telematics
F77A – 10 Amp Red
RR Entertainment Screen 1 & 2/
Media HUB 1 & 2/3rd Row USB
Charge Only/2nd Row USB Charge
Only/Vacuum Cleaner SW/3rd Row
Recline ST SW/LT & RT Stow N Go
SW/LT & RT Sliding Door SW
Backlight
F77B – 10 Amp Red Rain Sensor/Sunroof /CRVMM
F78A – 15 Amp Blue
Transmission Control Module
(TCM)/ E-Shifter
F78B – 15 Amp Blue Instrument Cluster
F79 – 10 Amp Red
ICS/Front And Rear HVAC/ SCCM/
EPB
F80 – – Not Used
F81 – – Not Used
F82 – – Not Used
F83
20 Amp Blue – TT Park Lights — If Equipped
30 Amp Pink –
Headlamp Washer Pump — If
Equipped
F84 30 Amp Pink –
Drive Train Control MOD — If
Equipped
F85 – 20 Amp Yellow Cigar Lighter
Cavity Cartridge Fuse Blade Fuse Description
8
