378 SERVICING AND MAINTENANCE
F86 – – Not Used
F87 – – Not Used
F88 – 20 Amp Yellow Front Heated Seats — If Equipped
F89 – 20 Amp Yellow Rear Heated Seats — If Equipped
F90 – – Not Used
F91 – 15 Amp Blue
Front Ventilated Seats/Heated
Steering Wheel — If Equipped
F92 – 5 Amp Tan Security Gateway
F93 – – Not Used
F94 40 Amp Green – ESC Motor Pump
F95A – 10 Amp Red USB Charge Port — ACC RUN
F95B – 10 Amp Red
Selectable Fuse Location – USB IP
(Direct) B+
F96 – 10 Amp Red
Occupant Restraint Controller
(ORC) (Airbag)
Cavity Cartridge Fuse Blade Fuse Description
