SERVICING AND MAINTENANCE 379
* 30 Amp mini fuse is substituted for 25 Amp Circuit Breaker.
F97 – 10 Amp Red
Occupant Restraint Controller
(ORC) (Airbag)
F98 – 15 Amp Blue Left HID Headlamp — If Equipped
F99 30 Amp Pink – Trailer Tow Module - If Equipped
F100A – 10 Amp Red AHLM — If Equipped
F100B – 10 Amp Red
Rear Camera/LBSS/RBSS/CVPM/
Humidity Sensor/In Vehicle
Temperature Sensor — If Equipped
Circuit Breakers
CB1 25 Amp Power Seats (Driver)
CB2 25 Amp * Power Seats (Pass)
CB3 25 Amp
FRT PWR Window W/O Door Nodes
+ RR PWR Window Lockout
Cavity Cartridge Fuse Blade Fuse Description
8
