Air handling units for
swimming pools
5
Junior BCP
Note: The serial number must be used in all communication
regarding the unit.
All units bear, legibly and indelibly, a data plate located in a prime
space, with the following data:
5. UNIT IDENTIFICATION
6. SAFETY ADVICE
To avoid any risk of accident during installation, commissioning or
maintenance, it is obligatory to take into consideration the following
specifications for the units: refrigerated circuits under pressure,
refrigerant presence, voltage presence and implantation. Because
of all of this, only qualifi ed and experienced personnel can perform
maintenance tasks or unit repairs.
These units work with refrigerant gas
Refrigerant leaks:
A periodical check must be performed for refrigerant gas leaks as per
Regulation (CE) Nº842/2006 over certain greenhouse effect fl uoride
gases.
Refrigerant leaks can cause:
- Displacement of available oxygen, its inhalation can cause
arrhythmias (work must be undertaken in well-ventilated areas).
- Eye irritations can result from contact as well as burns (suitable
safety goggles must be worn).
It is required to follow the recommendations and instructions
in the maintenance brochures, the labels, and the specifi c
instructions. It is necessary to comply with the norms and
regulations in effect.
The compressor and line surfaces can reach temperatures
above 100ºC causing burns to the body. In the same fashion,
under certain conditions these surfaces can reach very cold
temperatures that can cause freezing risks.
Use safety gloves and gloves whilst working. Be careful with
sharp parts or elements in the unit.
V-220005
V-220004
Caution: Before intervening in the unit, verify that the main
power to the unit is cut off. An electric shock can cause
personal damage.
Note: In order to recycle these units follow the stipulations
of Directives (EC) No. 96/2002 and No. 108/2003 regarding
electrical and electronic equipment and the management of
the resulting waste.
Ref. Produit\Item Nbr Designation\Description
An.Y
ear
No Serie\Serial Nbr \ No Produit
Refrigerant kW Absorbee\Input kW Poids\Weight
Refrigerant kg Tension\Voltage Temper ature Maxi C
BP Mini PSM\MOP Intensité\Current A IP
HP Maxi PSM\MOP Int.. Kit Elect. No CE
30, av JeanFalconnier
01350 CULOZ
Tel : 33(0)4 79 42 42 42
Made in Spain
Type de réfrigérant
Basse pression
Modèle
Nº ordre commande
Poids en fonctionnement
Tension du réseau
Haute pression
Nº ordre fabrication
Intensité kit electrique
7. TRANSPORT
The unit must be handled with care to avoid transport damage. Thus
we recommend:
- For large dimension units, appropriate transports should be used for
this purpose.
- For transport in a container, one must be selected that is easy to
load and unload.
- Do not dispose of the pallet nor the packaging materials until the
machine is in its fi nal location.
- Transport the units using the forklift truck or slings however only by
the hoisting points on the unit.
The slings must be separated using a strut to avoid deteriorating the
bodywork.
Components of the R-410A R-32 R-125 R-134A
Chemical formula CH2F2 CHF2CF3 CH2FCF3
Weight ratio 23% 25% 52%
Unitary global warming potential (GWP) 675 3.500 1.430
Global warming potential (GWP) 1.774
