13 - LIST OF CONTROL PARAMETERS WITH "ACCESS LEVEL 1"
Screen Parameter Description of the parameter Value Min. Max. UOM Type R/W
Add.
BMS
P01 PLAN_ADDRESS Address of the unit in the shared network 0 0 0 --- Integer R
P01 HORA Clock: hour 0 0 0 h Integer R 48
P01 MINUTO Clock: minute 0 0 0 min Integer R 47
P01 MODO_VENT VENTILATION operating mode 0 0 1 --- Digital R 236
P01 MODO_FRIO COOLING operating mode 0 0 1 --- Digital R 14
P01 GLOBAL_ALARM Signal of active alarms 0 0 1 --- Digital R 26
P01 TEMP_INT Indoor temperature for regulation of the unit 0.0 -99.9 0.0 °C Analog. R 291
P01 TEMP_EXT Temperature of the outdoor air 0.0 -99.9 0.0 °C Analog. R 2
P01 HUM_INT Indoor relative humidity for regulation of the unit 0.0 0.0 0.0 %rH Analog. R 5
P01 ESTADO_EQUIPO Unit status (ON, OFF, remote OFF, OFF by phase) 0 0 0 --- Integer R
P01 EN_FASE_HOR_NUEVA Indication of unit switch-on by schedule programming 001 --- Digital R
P01 DESHUMIDIFICA Indication of active dehumidifi er 0 0 1 --- Digital R 304
P01 HUMIDIFICA Indication of active humidifi er 0 0 1 --- Digital R 22
P01 ON_COMPENSACION Indication of active compensation 0 0 1 --- Digital R
P01 ON_DESESCARCHE Indication of active defrosting 0 0 1 --- Digital R 183
P01 ON_FREECOOL Indication of active free-cooling 0 0 1 --- Digital R 184
P01 ON_FREEHEAT Indication of active free-heating 0 0 1 --- Digital R 185
P01 LAMP_COMPRESOR Indication of compressors in operation 0 0 1 --- Digital R
P01 LAMP_VINT Indication of supply fans in operation 0 0 1 --- Digital R
P01 LAMP_RESISTENCIA Indication of electrical heaters in operation 0 0 1 --- Digital R
P01 ON_LIMITE_TEMP_IMPULSION Indication of unit in operation with limit of supply temperature 0 0 1 --- Digital R 238
P02 HORA Clock: hour 0 0 0 h Integer R 48
P02 MINUTO Clock: minute 0 0 0 min Integer R 47
P02 DIA Clock: day 0 0 0 day Integer R 49
P02 MES Clock: month 0 0 0 month Integer R 50
P02 ANO Clock: year 0 0 0 year Integer R 51
P02 MODO_FRIO VENTILATION operating mode 0 0 1 --- Digital R
P02 MODO_VENT COOLING operating mode 0 0 1 --- Digital R 236
P02 GLOBAL_ALARM Signal of active alarms 0 0 1 --- Digital R 26
P02 SET_TEMP_DISPLAY Active setpoint temperature 0.0 0.0 0.0 °C Analog. R
P02 ESTADO_EQUIPO ON/OF unit status 0 0 0 --- Integer R
P02 EN_FASE_HOR_NUEVA Indication of unit switch-on by schedule programming 001 --- Digital R
P02 DESHUMIDIFICA Indication of active dehumidifi er 0 0 1 --- Digital R
P02 HUMIDIFICA Indication of active humidifi er 0 0 1 --- Digital R 22
P02 ON_COMPENSACION Indication of active compensation 0 0 1 --- Digital R
P02 ON_DESESCARCHE Indication of active defrosting 0 0 1 --- Digital R 183
P02 ON_FREECOOL Indication of active free-cooling 0 0 1 --- Digital R 184
P02 ON_FREEHEAT Indication of active free-heating 0 0 1 --- Digital R 185
P02 LAMP_COMPRESOR Indication of compressors in operation 0 0 1 --- Digital R
P02 LAMP_VINT Indication of supply fans in operation 0 0 1 --- Digital R
P02 LAMP_RESISTENCIA Indication of electrical heaters in operation 0 0 1 --- Digital R
P02 ON_LIMITE_TEMP_IMPULSION Indication of unit in operation with limit of supply temperature 0 0 1 --- Digital R 238
P03 PLAN_ADDRESS Address of the unit in the shared network 0 0 0 --- Integer R
P03 HAB_SUPERVISION Enabling the supervision serial card (optional) 1 0 1 --- Digital R 50
P03 TIPO_PROT_COM Supervision protocol (Carel, Modbus) 1 0 0 --- Integer R 227
P03 BMS_ADDRESS Address of the unit in the supervision network 1 0 0 --- Integer R 228
P03 BAUD_RATE Bits rate (0=1200, 1=2400, 2=4800, 3=9600, 4=19200, 5=38400) 4 0 4 --- Integer R 229
P03 Stop_bits_Number_MB Number of stop bits for the MODBUS protocol (0 = 2 stop bits, 1= 1 stop bit) 0 0 1 --- Digital R 282
P03 Parity_Type_MB Type of parity (no parity, odd or even) 0 0 2 --- Integer R 230
P04 MODELO_EQUIPO Unit model 0 0 99 --- Integer R 58
P04 INFO_EQUIPO_1 Unit information: air-air, cooling-only, reversible 1 0 9 --- Integer R 191
P04 INFO_EQUIPO_2 Unit information: compressors-circuits (0,2c-1c,4c-2c) + recovery 1 0 99 --- Integer R 192
P04 UNICO_VOL_AIRE_EXT_CIRC_2 Selection of single-volume of outdoor air in 2-circuits units 0 0 1 --- Digital R
P04 TIPO_VENT_EXT Type of outdoor fan (3= 2 speeds axial fan; 4= electronic axial fan or plug-fan) 4 1 4 --- Integer R 1
P04 INFO_EQUIPO_3 Unit information: with electrical heaters - gas burner/boiler - hot water coil 1 0 9 --- Integer R 193
P04 TIPO_REFRIGERANTE Type of refrigerant (4=R410A, 5=R-454B) 4 0 5 --- Integer R 43
P04 NUM_WO_DIG_1 Work order number of the unit (digit 1) 0 0 9 --- Analog. R 185
P04 NUM_WO_DIG_2 Work order number of the unit (digit 2) 0 0 9 --- Analog. R 186
Parameters of “Unit Status”
01.Unit Status
Important: All parameters of level “1” are visible to the fi nal user without any password. Parameters with levels of access “2” and “3” are
protected by passwords and they can be found in the complete brochure of the Vectic control (NA1671G).
