Cideko AB03B - Chapter 3 Start up

3.1 Connections
1. Front Side
Chapter 3 Start Up
2. Left Side
3. Back Side
7
1. IR Receiver
2. Power Indicator
3. USB port x 2
3
1 2
2
SD/SDHCK9
1
1. K9: Please refer to the
last page, trouble
shooting
2. SD / SDHC card reader
1 2 3 4 5 6
7
LAN
HDMI
AudioYPbPr
Optical
12V-1.5A
1. Power Jack
2. USB port
3. RJ 45
LAN
HDMI
AudioYPbPr
Optical
12V-1.5A
LAN
HDMI
12V-1.5A
AudioYPbPr
Optical
GreenBlueRed
LAN
HDMI
AudioYPbPr
Optical
12V-1.5A
CIDEKO SIMPLE BOX ADVANCED
4. HDMI out (HDMI cable required)
5. Composite (Y.Pb.Pr.) out (convertor required)
6. Audio out (convertor required)
7. Optical digital audio output
