CipherLab 8000 Reference Manual

34
8000 Series Mobile Computer Reference Manual
3.3.6 ECHO TEST
After a physical connection is established properly, run a test utility on your computer
and start the test on your mobile computer. Select a desired baud rate if necessary.
 To stop and exit the test, press [ESC].
Interface
Description Test Utility
IR (Cradle-IR) This echo test is to verify connectivity via IR between the
mobile computer and any cradle.
EchoTest.exe
Modem This echo test is to verify connectivity via the Modem
Cradle. A telephone line must be connected to the Modem
Cradle.
EchoTest.exe
Note: For the Modem Cradle, any value other than 57600 bps (default) must be
configured through the DIP switch on the IR control board.

CipherLab 8000 Specifications

General

Operating System	Proprietary
Humidity	5% to 95% non-condensing
Barcode Scanner	Laser
Connectivity	RS-232
Ports	RS-232
Weight (Extended)	280g (with battery)
Storage Temperature	-20°C to 60°C
Drop Specification	1.2m
