CipherLab 8000 Reference Manual

70
8000 Series Mobile Computer Reference Manual
SETTINGS
Interface
Options Description
Cradle-IR (Serial IR) Proceed to configure baud rate settings on your computer and the
mobile computer.
IrDA Point to the target IrDA device.
Bluetooth Approach the target Bluetooth enabled device.
Baud Rate
Options Supported by CipherLab software, including download utilities
115200 (bps) Yes
76800 (bps) No
57600 (bps) Yes
38400 (bps) Yes
19200 (bps) Yes
9600 (bps) Yes
4800 (bps) No
2400 (bps) No
Note: If you select to use Serial IR of the Modem Cradle, any value other than 57600
bps (default) must be configured through the DIP switch on the IR control board.
LOAD PROGRAM VIA BLUETOOTH
1) Go to Kernel Menu | 5. Bluetooth Menu | 3. Security, and configure the following
Bluetooth settings first.
 Authentication
 PIN code
2) Go to Kernel Menu | 2. Load Program and select Bluetooth.
3) Start the pairing procedure from your computer, for example, click [Pair Device]
and/or [Connect Bluetooth Serial Port].
4) Run the download utility: ProgLoad.exe
- Select interface RS-232/IrDA for using Bluetooth SPP.
- Select COM port properties that match with the serial port settings used on your
computer.
Note: The interface option “Bluetooth” is only available on 8062.

CipherLab 8000 Specifications

General

Operating System	Proprietary
Humidity	5% to 95% non-condensing
Barcode Scanner	Laser
Connectivity	RS-232
Ports	RS-232
Weight (Extended)	280g (with battery)
Storage Temperature	-20°C to 60°C
Drop Specification	1.2m
