CipherLab 8300 User Manual

178
CipherLab BASIC Programming Part I
SYMBOLOGY PARAMETER TABLE FOR 2D/EXTRA LONG RANGE READER
No. (N1%)
Values (N2%) & Description
Default
Scan Engine
1 1: Enable Code 39
0: Disable Code 39
1
2D, (Extra)
Long Range
2 1 : Enable Code 32 (Italian Pharmacode)
0 : Disable Code 32
0
2D, (Extra)
Long Range
3 N/A --- ---
4 N/A --- ---
5 1: Enable Interleaved 25
0: Disable Interleaved 25
1
2D, (Extra)
Long Range
6 Matrix 25 0
8200, 8400,
8700 -2D
7 1: Enable Codabar (NW7)
0: Disable Codabar (NW7)
1
2D, (Extra)
Long Range
8 1: Enable Code 93
0: Disable Code 93
1
2D, (Extra)
Long Range
9 1: Enable Code 128
0: Disable Code 128
1
2D, (Extra)
Long Range
10 1: Enable UPC-E0
0: Disable UPC-E0 (depends)
1
2D, (Extra)
Long Range
11,
12
1: Enable Only Addon 2 & 5 of UPC & EAN Families
(It requires “ANY” of the indexes to be set 1.)
0: Disable Only Addon 2 & 5 of UPC & EAN Families
(It requires “ALL” of the indexes to be set 0.)
 Refer to 14, 15, 17, 18, 107, and 109.
0
2D, (Extra)
Long Range
13 1: Enable EAN-8
0: Disable EAN-8 (depends)
1
2D, (Extra)
Long Range
14,
15
See #11, #12. 0
2D, (Extra)
Long Range
16 1: Enable EAN-13
0: Disable EAN-13 (depends)
1
2D, (Extra)
Long Range
17,
18
See #11, #12. 0
2D, (Extra)
Long Range
19 1: Enable MSI
0: Disable MSI
1
2D, (Extra)
Long Range
Note: By default, MSI is disabled on 8200/8400/8700.
