CipherLab 8300 User Manual

209
Appendix II Symbology Parameters
UPC/EAN FAMILIES
The UPC/EAN families include No Addon, Addon 2, and Addon 5 for the following
symbologies:
 UPC-E0
 UPC-E1
 UPC-A
 EAN-8
 EAN-13
 Bookland EAN (ISBN)
For any member belonging to the UPC/EAN families, Index #139 is used to decide the
joint configuration of No Addon, Addon 2, and Addon 5. Other parameters are listed
below.
No. (N1%)
Values (N2%) & Description
Default
Scan Engine
43 1: Convert UPC-E0 to UPC-A
0: No conversion
0
2D, (Extra)
Long Range
44 1: Convert UPC-A to EAN-13
0: No conversion
0 8200
, 8400,
8700 2D
47 1: Transmit UPC-E0 Check Digit
0: DO NOT transmit UPC-E0 Check Digit
1
2D, (Extra)
Long Range
48 1: Transmit UPC-A Check Digit
0: DO NOT transmit UPC-A Check Digit
1
2D, (Extra)
Long Range
51 1: Transmit UPC-E0 System Number
0: DO NOT transmit UPC-E0 System Number
1
2D, (Extra)
Long Range
52 1: Transmit UPC-A System Number
0: DO NOT transmit UPC-A System Number
1
2D, (Extra)
Long Range
53 1: Convert EAN-8 to EAN-13
0: No conversion
1
2D, (Extra)
Long Range
91 1: Transmit UPC-E1 System Number
0: DO NOT transmit UPC-E1 System Number
0
2D, (Extra)
Long Range
92 1: Transmit UPC-E1 Check Digit
0: DO NOT transmit UPC-E1 Check Digit
0
2D, (Extra)
Long Range
95 1: Convert UPC-E1 to UPC-A
0: No conversion
0
2D, (Extra)
Long Range
141 1: Enable UPC-A System Number & Country Code
0: Disable UPC-A System Number & Country Code
1
2D, (Extra)
Long Range
142 1: Enable UPC-E0 System Number & Country Code
0: Disable UPC-E0 System Number & Country Code
1
2D, (Extra)
Long Range
