CipherLab 8300 User Manual

207
Appendix II Symbology Parameters
MSI
No. (N1%)
Values (N2%) & Description
Default
Scan Engine
19 1: Enable MSI
0: Disable MSI
1
2D, (Extra)
Long Range
Note: By default, MSI is disabled on 8200/8400/8700.
39 MSI Check Digit Verification
2: Modulo 11 and Modulo 10
1: Double Modulo 10
0: Single Modulo 10
1
2D, (Extra)
Long Range
40 MSI Check Digit Transmission
2: Both Check Digits are NOT transmitted
1: Both Check Digits are transmitted
0: Last Check Digit is NOT transmitted
0
2D, (Extra)
Long Range
67 1: MSI 25 Code Length Limitation in Max/Min Length Format
0: MSI 25 Code Length Limitation in Fixed Length Format
1
2D, (Extra)
Long Range
68 MSI Max Code Length / Fixed Length 1 Max. 31
2D, (Extra)
Long Range
69 MSI Min Code Length / Fixed Length 2
Note
Length1 must be greater than Length2.
Min. 3
2D, (Extra)
Long Range
Verify Check Digit
Select one of the three calculations to perform check digit verification when decoding barcodes.
 If true and the check digit found incorrect, the barcode will not be accepted.
Transmit Check Digit
Decide whether or not to include the check digit in the data being transmitted.
Length Qualification
Because of the weak structure of the symbology, it is possible to make a “short scan”
error. To
prevent the “short scan” error, define the “Length Qualification”
settings to ensure that the correct
barcode is read by qualifying the allowable code length. Refer to Codabar.
