CipherLab 8300

189
Each of the scan engines can decode a number of barcode symbologies. This appendix
describes the associated symbology parameters accordingly.
IN THIS CHAPTER
Scan Engine, CCD or Laser .............................................. 189
Scan Engine, 2D or (Extra) Long Range Laser .................... 202
2D Scan Engine Only ...................................................... 214
SCAN ENGINE, CCD OR LASER
CODABAR
No. (N1%)
Values (N2%) & Description
Default
Scan Engine
7 1: Enable Codabar (NW7)
0: Disable Codabar (NW7)
1 CCD, Laser
,
8700 –
Long
Range
37 Select Codabar Start/Stop Character
3: ABCD/TN*E
2: ABCD/ABCD
1: abcd/tn*e
0: abcd/abcd
0 CCD, Laser
,
8700 –
Long
Range
38 1: Transmit Codabar Start/Stop Character
0: DO NOT transmit Codabar Start/Stop Character
0 CCD, Laser
,
8700 –
Long
Range
315 1: Skip checking Codabar quiet zone
0: Check Codabar quiet zone
0 8200/8400
CCD, Laser
Select Start/Stop Character
Select no start/stop characters,
or one of the four different start/stop character pairs to be
included in the data being transmitted.
 abcd/abcd
 abcd/tn*e
 ABCD/ABCD
 ABCD/TN*E,
Transmit Start/Stop Character
Decide whether or not to include the start/stop characters in the data being transmitted.
Appendix II
SYMBOLOGY PARAMETERS
