Controls (continued)
LED INDICATOR LIGHTS:
• Power: Located on the Power Button, this LED indicates that the Control Module is receiving input power when
illuminated.
SAFETY TIP: Using the Power Button to turn the system off DOES NOT remove power from the control
box. Always disconnect power at the circuit breaker prior to attempting any service procedure.
• Generate: This LED is illuminated intermittently during normal operation, and indicates that the system is
currently generating chlorine. IMPORTANT: this light will be off during normal rest periods of the system's duty
cycle (see “Duty Cycle” below). When flashing, the pool water is either too hot or too cold for chlorine generation.
• Super CL: Located on the Super CL Button, this LED is illuminated when the Super CL mode has been activated.
• Winter Mode: Located on the Winter Mode Button (snow flake icon), this LED is illuminated when the winter
mode has been activated.
• Salinity: Located on the Salinity button, this LED is illuminated when the button has been pressed to display the
salt level reading.
• Remote: This LED indicates that the unit is controlled by a remote control system.
• No Flow: This LED is illuminated when the Flow Switch has detected no flow. This causes the Cell to stop
generating chlorine. A flashing LED indicates that the flow is restored, but there will be up to a 60 second delay
before generation is reestablished.
• Cell Maint.: This LED is illuminated when Cell efficiency is greatly reduced and the Cell has stopped generating.
- Important: This will eventually happen with normal operation and indicates the Cell must be cleaned (see
page 12). Read and follow all cleaning instructions closely. This light takes priority over any salinity readings
or indicator lights, as salinity readings may temporarily be displayed as artificially low during such conditions.
- If illuminated after thorough cleanings and after verifying system parameters, Cell replacement may be
necessary. This light may also turn on due to improper salinity, insufficient water in cell, or having the wrong
cell version set in the Menu.
• Lo Salt: When this LED is illuminated, the salt level is near to its minimum threshold, and the Cell has shut down.
The salt level must be raised before operation is restored. See also "Cell Maint." above. See page 4 for information
about adding salt.
• Hi Salt: When this LED is illuminated, the salt level is too high, and the Cell has shut down. The pool water must be
diluted with fresh water before operation is restored. See also "Cell Maint." above.
Chlorine Generation Duty Cycle
At times you will see the “Generate” LED light turned off during normal operation – this simply indicates the system
is in the resting portion of its duty cycle. No action is required on your part. The RJ Series uses an algorithm that
determines when it is actively generating chlorine. The lower the chosen chlorine output power level, the less
frequently the “Generate” LED will be lit, and vice versa. This feature helps maximize the lifespan of your Cell.
