SMALL 3 MODULE SIZE
DIN RAIL
PANEL (ADAPTER ACCESSORY)
BACKLIT
LCD DISPLAY
GREEN Normal operation
status.
RED Trip status by fault or
other event.
INSTANT CURRENT
LEAKAGE DISPLAY
PRE-ALARM
RELAY
SENSITIVITY from 50 to
80%I
∆N
DELAY from 20 ms to 10
seconds
OUTPUT RELAY
CONTACT STATUS
RS-485 MODBUS
COMMUNICATIONS
SETTING OF PARAMETERS
SENSITIVITY from 30 mA to
30 A
DELAY from 20 ms to 10
seconds
ASSOCIATED
BREAKING DEVICE
CONTACTOR. Connection by
undervoltage coil
EARTH LEAKAGE DEVICE
WITH TRIP COIL
TRIP COIL
· MINIMUM Voltage
· Current EMISSION
ASSOCIATED
MEASURING DEVICE
EARTH LEAKAGE TOROID.
WG/WGS FAMILY
