MAIN FEATURES
 Measuring in true effective value (TRMS)
 Type A differential. IEC 61008.1
 Insulation against transients. IEC 61008.1
 High frequency filtering. IEC 61008.1
 Trip setting between 80 and 100% I
∆
N
 Inverse curve. IEC 61008.1
 Associated standard IEC 61008.1, IEC 38
Other features:
 3 modules. DIN rail. In a panel using front accessory, code M5ZZF1
 Displaying instant leakage values.
 Backlit LCD display.
 Built-in RS485 communications (Modbus RTU®). RGU-10C only
Available models:
RGU-10 SERIES CODE
RGU-10 P11941
RGU-10C P11944

Circutor RGU-10 Specifications

General

Power Supply	230 V AC
Mounting	DIN rail
Rated voltage	230 V AC
Number of poles	1
Frequency	50/60 Hz
Contact material	Silver alloy
Protection degree	IP20
Electrical life	> 10^5 operations
Operating temperature	-10 to +50 ºC
Storage temperature	-20°C to +70°C
Output Contacts	1 changeover (CO)
