Key-hole
slots
Horizontal
spacing:
3.100in
(78.74mm)
V
ertical
spacing:
5.758inin
(146.25mm)
1
Figure
15:
Wall
mount
using
key-hole
slots
-
C1126-8PL
TEP
Install
and
Connect
the
Router
14
Install
and
Connect
the
Router
Wall
Mount
Using
Key-hole
Slots
13
15
