3-48
Cisco 3600 Series Routers Hardware Installation Guide
OL-2056-05
Chapter 3 Installing the Router
Connecting to a Console Terminal or Modem
Figure 3-63 Connecting a Modem to the Auxiliary Port on the Cisco 3640 Router
H7222
0
ACTIVE
READY
123
PCMCIA
1
0
S
Y
S
T
E
M
C
O
N
A
U
X
R
P
S
AUX port (RJ-45)
Modem cable
Modem
RJ-45-to-DB-25 adapter
EIA/TIA-232
