Cisco 3745 Installation Guide

1-12
Cisco 3700 Series Routers Hardware Installation Guide
OL-2180-08
Chapter 1 Overview of Cisco 3700 Series Routers
Regulatory Compliance
Regulatory Compliance
For compliance information, see the Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series
Regulatory Compliance and Safety Information document that accompanied the router.
Power dissipation 230 W (maximum)
Heat Dissipation 230W Maximum 784.829 BTU/hour, 590W Maximum 2013.257
BTU/hour
Console and auxiliary ports RJ-45 connector
Operating humidity 5–95%, noncondensing
Operating temperature 32–104°F (0–40°C)
1
Nonoperating temperature –40 to 162°F (–40 to 72°C)
Noise level 60 dBA (maximum)
Regulatory compliance FCC Part 15 Class A.
For additional compliance information, see the Cisco 2600 Series,
Cisco 3600 Series, and Cisco 3700 Series Regulatory Compliance
and Safety Information document that accompanied the router.
Safety compliance UL 60950; CAN/CSA C22.2 No. 60950-00; IEC 60950;
AS/NZS 3260; TS001
1. Because of increased power consumption in high-temperature environments, a fully loaded Cisco 3745 router requires both
power supplies when ambient temperature exceeds 104˚F (40˚C).
Table 1-5 Cisco 3745 Router System Specifications (continued)
Description Specification

Cisco 3745 Specifications

General

Form Factor	Rack-mountable
Network Module Slots	4
Advanced Integration Module Slots	2
Product Type	Router
Connectivity Technology	Wired
Data Transfer Rate	100 Mbps
Data Link Protocol	Ethernet, Fast Ethernet
Encryption Algorithm	DES, 3DES, AES
Authentication Method	RADIUS, TACACS+
Operating System	Cisco IOS
Power Supply	AC 120/230 V (50/60 Hz)
Operating Temperature	32 to 104 °F (0 to 40 °C)
Storage Temperature	-4 to 149 °F (-20 to 65 °C)
Interfaces	10/100 Ethernet
RAM	256 MB
Flash Memory	128 MB (max)
Dimensions	17.5 inches
Network / Transport Protocol	TCP/IP
Remote Management Protocol	SNMP, Telnet, HTTP
Humidity	10% to 85% non-condensing
Processor	Motorola PowerPC
