Cisco 3800 Series User Manual

LEDs
44
Troubleshooting Cisco 3800 Series Routers
OL-5972-01
AUX PWR Front — Off IP phone power off or not present, or power-up
not completed
Steady green Present and enabled (power-up completed)
Amber Powered but malfunctioning
AUX PWR1 — Front Off IP phone power supply 1 off or not present, or
power-up not completed
Steady green Present and enabled (power-up completed)
Amber Powered but malfunctioning
AUX PWR2 — Front Off IP phone power supply 2 off or not present, or
power-up not completed
Steady green Present and enabled (power-up completed)
Amber Powered but malfunctioning
AIM0 Front Rear Off AIM0 not present
Green Present and enabled
Amber Present but malfunctioning
AIM1 Front Rear Off AIM1 not present
Green Present and enabled
Amber Present but malfunctioning
PVDM0 Front Rear Off PVDM0 not present
Green Present and enabled
Amber Present but malfunctioning
PVDM1 Front Rear Off PVDM1 not present
Green Present and enabled
Amber Present but malfunctioning
PVDM2 Front Rear Off PVDM2 not present
Green Present and enabled
Amber Present but malfunctioning
PVDM3 Front Rear Off PVDM3 not present
Green Present and enabled
Amber Present but malfunctioning
CF Front Rear Off CompactFlash memory card not being accessed
Steady green CompactFlash card being accessed; do not eject
Blinking green CompactFlash card being accessed; do not eject
SFP Rear Rear Off SFP link not established
Green SFP port active, link established
GE0: Link Rear Rear Off No link
Green Ethernet cable present, link established
Table 5 Cisco 3800 Series LED Indicators (continued)
LED 3825 3845 Color and State Meaning

Cisco 3800 Series Specifications

General

Connectivity Technology	Wired
Models	Cisco 3825, Cisco 3845
Operating System	Cisco IOS
Routing Protocols	BGP, OSPF, EIGRP, RIP, IS-IS
Interfaces	Fast Ethernet, Gigabit Ethernet, Serial, ISDN BRI, Voice
WAN Interfaces	T1/E1, ISDN BRI, Serial
Security Features	Firewall, VPN, IPS, SSH
Voice Support	Yes
Network Management	SNMP, CLI
Product Type	Router
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Network/Transport Protocol	TCP/IP
Features	Quality of Service (QoS)
RAM	256 MB
Flash Memory	64 MB
Product Series	Cisco 3800 Series
