Cisco 3845 - Security Bundle Router Quick Start Guide

27
SYS PWR2 — Front Off Power system 2 not present
Steady green Present and enabled
Amber Present and malfunctioning
AUX PWR Front — Off IP phone power off
Steady green Normal operation
Amber Powered but malfunctioning
AUX PWR1 — Front Off IP phone power system 1 not present
Steady green Present and enabled
Amber Powered but malfunctioning
AUX PWR2 — Front Off IP phone power system 2 not present
Steady green Present and enabled
Amber Powered but malfunctioning
AIM0 Front Rear Off AIM0 not present
Green Present and enabled
Amber Present but malfunctioning
AIM1 Front Rear Off AIM1 not present
Green Present and enabled
Amber Present but malfunctioning
PVDM0 Front Rear Off PVDM0 not present
Green Present and enabled
Amber Present but malfunctioning
PVDM1 Front Rear Off PVDM1 not present
Green Present and enabled
Amber Present but malfunctioning
PVDM2 Front Rear Off PVDM2 not present
Green Present and enabled
Amber Present but malfunctioning
PVDM3 Front Rear Off PVDM3 not present
Green Present and enabled
Amber Present but malfunctioning
CF Front Rear Off Flash memory not being accessed
Steady green Flash memory is being accessed; do not eject the
CompactFlash memory card
Blinking green Flash memory is being accessed; do not eject the
CompactFlash memory card
SFP Rear Rear Off SFP link not established
Green SFP port active, link established
GE0: Link Rear Rear Off No link
Green Ethernet cable present, link established
Table 5 Cisco 3800 Series LED Indicators (continued)
LED
Cisco
3825
Router
Cisco
3845
Router Color and State Meaning
