Cisco 3845 - Security Bundle Router Quick Start Guide

25
System Management Connections
The connections described in Table 4 provide system management access.
Note The USB ports (version 1.1) are intended for future use only.
6 Power Up the Router
Caution To ensure adequate cooling, never operate the router unless the cover and all modules and cover plates are installed.
Checklist for Power Up
You are ready to power up the Cisco 3800 series router after the following steps are completed:
• Chassis is securely mounted and grounded. (See the “Install Chassis” section on page 5.)
• Power and interface cables are connected. (See the “Connect Cables” section on page 15.)
• PC with HyperTerminal or similar terminal emulation program is connected to the console port, powered up, and
configured for 9600 baud, 8 data bits, 1 stop bit, no flow control, and no parity. (See the “Power Connections” section on
page 16.)
• Suitable PC COM port is selected in the terminal emulation program.
• You have selected passwords for access control.
• You have determined the IP addresses for the Ethernet and serial interfaces.
Note For initial power-up, a direct console connection is recommended. After the initial configuration is completed, a remote
modem connection can be used for router management.
BRI NT/TE
(built-in NT1)
RJ-45, orange ISDN terminal equipment and
ISDN network
RJ-45 straight-through in TE mode
BRI crossover in NT mode
56/64-kbps
CSU/DSU
8-pin modular, blue RJ-48S interface in subrate device
or network
RJ-48 straight-through
T1/FT1 CSU/DSU 8-pin modular, blue RJ-48C interface RJ-48 straight-through
Gigabit Ethernet SFP,
optical
LC, color according
to optical wavelength
1000BASE-SX, -LX, -LH, -ZX,
-CWDM
Optical fiber as specified on applicable
data sheet
1. The color codes are specific to cables shipped by Cisco.
2. See the Cisco Modular Access Router Cable Specifications document for information about selecting these cables.
Table 4 System Management Connections
Port Color Connected To Cable
Console Light blue PC or ASCII terminal communication port
(usually labeled COM)
RJ-45-to-DB-9 console cable
Auxiliary Black Modem for remote access RJ-45-to-DB-25 modem cable or
RJ-45-to-DB-9 console cable and DB-9
to DB-25 adapter
Table 3 WAN, LAN, and Voice Connections
Port or Connection Port Type, Color
1
Connection Cable
