24
Warning
Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the
network interface.
Statement 1037
Warning
Class 1 laser product.
Statement 1008
Caution To comply with the Telcordia GR-1089 NEBS standard for electromagnetic compatibility and safety, connect
Gigabit Ethernet ports using RJ-45 connectors for shielded twisted pair cable only to intra-building or unexposed
wiring or cable. The intrabuilding cable must be shielded and the shield must be grounded at both ends. The
intra-building port(s) of the equipment or subassembly must not be metallically connected to interfaces that connect
to the OSP or its wiring. These interfaces are designed for use as intra-building interfaces only (Type 2 or Type 4
ports as described in GR-1089-CORE, Issue 4) and require isolation from the exposed OSP cabling. The addition
of Primary Protectors is not sufficient protection in order to connect these interfaces metallically to OSP wiring.
Table 3 summarizes some typical WAN, LAN, and voice connections for the Cisco 3800 series routers.
Table 3 WAN, LAN, and Voice Connections
Port or Connection Port Type, Color
1
Connection Cable
Ethernet RJ-45, yellow Ethernet switch Category 5 or higher Ethernet
T1/E1 WAN
xCE1T1-PRI
RJ-48C/CA81A
RJ-48S, tan
T1 or E1 network
External T1 CSU or other
T1 equipment
RJ-48 T1/E1
RJ-48S to RJ-48S TE; RJ-48S to RJ-48S NT;
RJ-48S to RJ-48S T1’ RJ-48S to bare
RJ-48S to BNC; RJ-48S to twinaxial cable
RJ-48S to DB-15
RJ-48S to DB-15 null
T3/DS3/E3 WAN BNC connector T3 network, CSU/DSU, or other
T3/DS3 equipment
75-ohm coaxial cable
OC3 / STM-1 WAN SC connector OC3/STM-1 network or device Single-mode or multimode optical fiber
Cisco serial 60-pin D-sub, blue CSU/DSU and serial network or
equipment
Cisco serial transition cable that matches
the signaling protocol (EIA/TIA-232,
EIA/TIA-449, V.35, X.21, or EIA-530)
and the serial port operating mode (DTE
or DCE).
2
Cisco Smart serial Cisco Smart compact
connector, blue
CSU/DSU and serial network or
equipment
ADSL RJ-11C/CA11A,
lavender
Network demarcation device for
service provider’s DSL interface
RJ-11 straight-through
SHDSL RJ-11C/CA11A,
lavender, RJ-14
Network demarcation device for
service provider’s DSL interface
RJ-11 straight-through for 2-wire
RJ-14 straight-through for 4-wire
T1/E1 digital voice RJ-48C/CA81A, tan Digital PBX, ISDN network,
CSU/DSU
RJ-48 T1/E1
Analog voice FXS RJ-11, gray Telephone, fax RJ-11; RJ21 if using NM-HDA,
straight-through
Analog voice FXO RJ-11, pink Central office, analog PBX
Analog voice E&M RJ-45, brown Analog PBX RJ-45
BRI S/T WAN
(external NT1)
RJ-45/CB-1D, orange NT1 device or private integrated
network exchange (PINX)
RJ-45 straight-through
BRI U WAN
(built-in NT1)
RJ-49C/CA-A11, red ISDN network RJ-48 straight-through
