Figure 16: SFP
Bail clasp2Dust plug1
Transmit optical bore4Receive optical bore3
Safety Warnings
Take note of the following optical connection warnings:
Statement 1051—Laser Radiation
Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into beams
or view directly with optical instruments.
Warning
Statement 1055—Class 1/1M Laser
Invisible laser radiation is present. Do not expose to users of telescopic optics. This applies to Class 1/1M
laser products.
Warning
The following table lists the Cisco supported transceivers.
Table 10: Supported Cisco SFP/SFP+ Transceivers
PIDOptics Type
1 Gb
GLC-SX-MMD1G-SX
GLC-LH-SMD1G-LH/LX
GLC-EX-SMD1G-EX
Cisco Firepower 4112, 4115, 4125, and 4145 Hardware Installation Guide
26
Overview
Supported SFP/SFP+ and QSFP Transceivers
