CHAPTER 5
Supported RAID Controllers and Required Cables
Table 7:
Full Disk
Encryption
SCPM
1
Required
Cables
RAID LevelsMaximum
Front-Facing
Drives
Controlled
StyleController
Yes
3
Not AvailableNot required0, 1, JBODSFF drives: 2
internal drives
PCIeENCS-MRAID
Controller
This
controller
cannot
be
ordered
with
FBWC.
2
Note
1 SCPM = SuperCap power module (RAID backup unit).
2 FBWC: modular flash-based write cache.
3 When using SED drive.
RAID Cabling
Cisco ENCS-MRAID card does not require additional cable to connect hard drives and RAID card. The flex
cable connected to the mainboard can be used to connect to RAID card.
RAID Card LED Indicator
When RAID card is installed, the LED indicator in the front bezel should turn in solid green.
RAID Card Firmware Compatibility, on page 38
ENCS-MRAID Controller Considerations, on page 38
Support Matrix For ENCS-MRAID Controller, on page 38
Drive Types and Sizes Supported, on page 39
ENCS-MRAID Drive and Predictive Failure Behavior, on page 39
Setting the Preferred Boot Device Order for ENCS-MRAID, on page 39
