Cisco 6821 Installation Guide

Installation Guide for Cisco IP Phone with Multiplatform Firmware
26
Wall Mount Your 8800 Series Phones
Wall Mount Your Phone
Wall Mount Your 8851 or 8861 Phone with a KEM Attached
Mount the wall bracket in the desired location.
1
Plug in the handset cable, then attach the phone
bracket to the rear panel of the phone and KEM
assembly.
2
447142
Components:
1. Six #8-18 x 1.25-inch Phillips-head
screws with
2. Six anchors
3. One phone bracket
4. One wall bracket
5. Three K30x8mm self-tapping
screws
6. One 6-inch Ethernet cable
1 2 3 4
5
6
447345
1
2
4
3
5
447346

Cisco 6821 Specifications

General

Resolution	320 x 240 pixels
Speakerphone	Yes
Headset Port	Yes
Protocols	SIP
USB Port	No
Wireless	No
Bluetooth	No
Video Support	No
Conference Capabilities	Yes
Wall Mountable	Yes
Display	3.5-inch grayscale
Ethernet	10/100 Ethernet
Line Keys	2
PoE	IEEE 802.3af Power over Ethernet (PoE)
Codecs	G.711, G.722, G.729, iLBC
Weight	2.0 lb (0.91 kg)
