Cisco 6921 Administration Guide

7-3
Cisco Unified IP Phone 6921, 6941, 6945, and 6961 Administration Guide for Cisco Unified Communications Manager 8.6 (SCCP and SIP)
OL-24567-01
Chapter
Status Menu
To display the Status Messages screen, follow these steps:
Procedure
Step 1 Press the Applications button.
Step 2 Select Admin Settings.
Step 3 Select Status.
Step 4 Select Status Messages.
To remove current status messages, press the Clear softkey.
To exit the Status Messages screen, press the Back softkey.
Table 7-2 Status Messages on the Cisco Unified IP Phone 6900 Series
Message Description Possible Explanation and Action
CFG file not found The name-based and default
configuration file was not found on the
TFTP Server.
The configuration file for a phone is created when the
phone is added to the Cisco Unified Communications
Manager database. If the phone has not been added to
the Cisco Unified Communications Manager
database, the TFTP server generates a
CFG File Not
Found
response.
• Phone is not registered with Cisco Unified
Communications Manager.
You must manually add the phone to Cisco
Unified Communications Manager if you are not
allowing phones to auto-register. See the
“Adding Phones with Cisco Unified CM
Administration” section on page 2-10 for details.
• If you are using DHCP, verify that the DHCP
server is pointing to the correct TFTP server.
• If you are using static IP addresses, check
configuration of the TFTP server. See the
“Network Setup Menu” section on page 4-4 for
details on assigning a TFTP server.
CFG TFTP Size Error The configuration file is too large for file
system on the phone.
Power cycle the phone.
Checksum Error Downloaded software file is corrupted. Obtain a new copy of the phone firmware and place it
in the TFTPPath directory. You should only copy files
into this directory when the TFTP server software is
shut down, otherwise the files may be corrupted.
