7-7
Cisco Unified IP Phone 6921, 6941, 6945, and 6961 Administration Guide for Cisco Unified Communications Manager 8.6 (SCCP and SIP)
OL-24567-01
Chapter
Status Menu
Step 4 Select Status > Network Statistics.
To reset the Rx Frames, Tx Frames, and Rx Broadcasts statistics to 0, press the Clear softkey.
To exit the Network Statistics screen, press the Back softkey.
Table 7-3 Network Statistics Message Information for the
Cisco Unified IP Phone 6900 Series
Item Description
Tx Frames Number of packets sent by the phone
Tx Broadcasts Number of broadcast packets sent by the phone
Tx Unicast Total number of unicast packets transmitted by the phone
Rx Frames Number of packets received by the phone
Rx Broadcasts Number of broadcast packets received by the phone
Rx Unicast Total number of unicast packets received by the phone
Neighbor Device ID:
• Neighbor IP Address
• Neighbor Port
Identifier of a device connected to this port discovered by CDP
protocol.
Restart Cause—One of these values:
• Hardware Reset (Power-on reset)
• Software Reset (memory
controller also reset)
• Software Reset (memory
controller not reset)
• Watchdog Reset
• Unknown
Cause of the last reset of the phone
Port 1 Link state and connection of the PC port (for example,
Auto
100 Mb Full-Duplex
means that the PC port is in a link-up
state and has auto-negotiated a full-duplex, 100-Mbps
connection)
