E-3

Cisco Unified IP Phone 6921, 6941, 6945, and 6961 Administration Guide for Cisco Unified Communications Manager 8.6 (SCCP and SIP)

OL-24567-01

Appendix

Installing the Bracket

Figure E-2 Mounting the Wall Bracket

Level wall

bracket on wall

Mark mounting

holes through

bracket on wall

274936

C D

Insert anchors

into wall

Screw bracket

to wall using

Phillips head

screws
